| Engine form: | water-cooled permanent magnet synchronous motor |
| Voltage capacitance: | 144V58AH (8.35Kw/H) |
| Maximum power： | 20kw(4000RPM) |
| Wheelbase: | 1375mm |
| Transmission: | DID oil-sealed silent chain |
| Battery form: | air-cooled lithium-ion high-voltage battery |
| Length, width and height: | 2028 X 684 X 1108 (mm) |
| Vehicle mass: | 185KG |
| Maximum torque: | 450 N-m |
| Maximum speed: | 150Km/h |
| Range: | 150Km |
| Hundred kilometers acceleration: 3 s | 3 s |
| Seat height: | 785mm |
| Minimum ground clearance: | 165mm |
| Frame: | All-aluminum alloy double-beam frame, aluminum alloy sub-frame |
| Suspension System: | 41mm inverted double-damping adjustable front shock absorber//central full-function adjustable shock absorber with aluminum alloy double swing arm |
| Brake System: | 310mm dual discs with 4-piston calipers (ABS) // 220mm single discs with single-piston calipers (ABS) |
| Tires: | Pirelli (DIABLO ROSSOIII) 120/70 ZR17 M/C 58W /// Pirelli (DIABLO ROSSOIII) 160/60 ZR17 M/C 69W |
Engine: In-line four cylinder/water cooled /DOHC/16 valve
Engine: In-line twin/water cooled /DOHC/8 valves
Engine: In-line twin/liquid cooled /DOHC/8 valves
Vehicle Model: Atr2 track only
